Primary Drive Clutch Rebuild Kit for Can-Am Renagade T 650 EFI 2018-2014
Primary Drive Clutch Rebuild Kit for Can-Am Renagade T 650 EFI 2018-2014
Primary Drive Clutch Rebuild Kit for Can-Am Renagade T 650 EFI 2018-2014
PremiumQuality Replacement Part
Primary Drive Clutch Rebuild Kit
For Can-Am Models:
Outlander 650 EFI SDT XT DPS XMR 2007-2024
Outlander T 650 2018-2024
Outlander Max 650 EFI SDT XT DPS XMR 2007-2024
Outlander 570 EFI 2019-2023
Outlander T Max 570 EFI 2018-2023
Renagade T 650 EFI 2018-2014
Order Includes:
6 x Clutch Weight (Centrifugal Lever Set) | 420248558
Length : 55 mm | 2.16″
Width : 15 mm | 0.59″
Weight Code: 554
30 Gram
1 x Clutch Spring | 420238610
Length : 95.5 mm | 3.76″
Inner Diameter : 51.40 mm | 2.02″
1 x Bolt | 420641859 420641852 420641855 711641147
Length : 147 mm | 5.78″
Head Diameter : 17.7 mm | 0.69″
M12x1.75
6 x Roller Sleeve | 417223257 417223257
Outer Diameter : 8 mm | 0.31″
Inner Diameter : 5.1 mm | 0.20″
Length : 29.3 mm | 1.15″
1 x Spring Seat | 420627577 420627578
Outer Diameter : 55 mm | 2.16″
Inner Diameter : 32 mm | 1.26″
Width : 16.1 mm | 0.63″
1 x Pulley Clutch | 420257195 711257194
Outer Diameter : 54.9 mm | 2.16″
Inner Diameter : 39.8 mm | 1.56″
Width : 31.8 mm | 1.25″
1 x Friction Washer | 420460430
Outer Diameter : 52 mm | 2.04″
Inner Diameter : 45.8 mm | 1.8″
Thickness : 2.0 mm | 0.07″
12 x Shoe Slider Set | 420281291 420281296
Outer Diameter : 16.9 mm | 0.66″
Thickness : 4.1 mm | 0.16″
1 x Retaining Ring | 420245951
Outer Diameter : 65.2 mm | 2.56″
Thickness : 0.97 mm | 0.038″
