Description
Drum feature:
5 on 4.5″ bolt pattern
5 x 1/2″-20 studs installed
2 x bearing races installed
Replace part #. 008-247-05, 84546
Brake features:
1 LH + 1 RH 10″x2-1/4″ electric trailer brake assemblies
Center hole dia: 3″
Mounting bolt circle dia: 4″
Works on Dexter and other brands 3500 lbs axle in the market
This drum and brakes have been sold by large quantity to trailer axle manufacturers nationwide
Include:
2 x 5 on 4.5 brake drums
1 x 10″x2-1/4″ electric brake assembly LH
1 x 10″x2-1/4″ electric brake assembly RH
2 x L68149 inner cone bearings
2 x L44649 outer cone bearings
2 x Grease seals 1.719″x 2.565″
2 x E Z lube dust caps w/ rubber plug
10 x cone wheel nuts 1/2-20″ thread
