Premium Quality Replacement Part
Deck Spindle Blade Bolts
For Deck Blade
Compatible with Exmark Models:
Explorer Zero-Turn Mowers
18hp Koh. 44″ Deck
EXS-18KO-2 (SN: 060000 – 089999) (1991-1993)
EXS-18KO (SN: 060000 – 089999) (1991-1993)
20hp Koh. 44″ Deck
EXS-20KC-2 (SN: 060000 – 101999) (1991-1994)
EXS-20KC (SN: 090000 – 101999) (1994)
EXS-20KO (SN: 060000 – 089999) (1991-1993)
20hp Koh. 44″ & 52″ Deck
EXS-20KC-2 (SN: 102000 – 129999) (1995-1996)
EXS-20KC (SN: 102000 – 129999) (1995-1996)
52″ Turf Ranger Front Mount Mower
FMD52 (SN: 060000 – 114999) (1991-1995)
52″ Turf Tracer Hydro Walk-Behind Mower
FMD52 (SN: 070000 – 079999) (1992)
For Vibratory Plow Assembly
Compatible with Toro Models:
Vibratory Plow for Dingo Compact Utility Loader
22437 (SN: 099000001 – 099999999) (1999)
22910 (SN: 200000001 – 200999999) (2000)
(SN: 210000001 – 210999999) (2001)
(SN: 230000001 – 230999999) (2003)
(SN: 240000001 – 240999999) (2004)
(SN: 250000001 – 250999999) (2005)
(SN: 260000001 – 260999999) (2006)
22911 (SN: 270000001 – 270999999) (2007)
(SN: 280000001 – 280999999) (2008)
(SN: 290000001 – 290999999) (2009)
(SN: 310000001 – 316999999) (2010-2016)
(SN: 400000000 – 401999999)
(SN: 404320000 – 999999999)
Order Includes :
3 x Bolt & Washer: 1-513435, 3213-1, 1-800531, E513435, 3290-450
Length: 32.8 mm – 1.29 in
Stud Length: 25mm – 0.98 in
Head Diameter: 18.8mm – 0.74 in
Thread Size: 1-2-20
Blade Part Number: 1-513262, 103-3294, 1-513263
103-3293, 1-513264, 1-513435, 1-603283
103-3233-S, 103-3229, 1-603637
Spindle Part Number: 1-513186, 1-414315, 1-514214
